Product Description:
The cleaning process takes between 5-10 minutes, depending on the
level of contamination on the wafers. The cleaning pressure is
adjustable between 3~8kg/cm2, allowing for a gentle or more
aggressive cleaning depending on the need. The wash liquid spray
pressure can also be adjusted to accommodate different types of
chips, making it a versatile machine for a variety of cleaning
needs.
The Semiconductor Cleaning Machine is equipped with two air
filters, one with a 1um filter and the other with a 0.01um filter.
This ensures that the wafers are cleaned to a high level of purity,
free from any contaminants that may affect the performance of the
final product.
The machine has a cleaning capacity of 100 wafers per hour, making
it suitable for both small and large-scale operations. It is also
designed with SMEMA lines to connect up and downstream equipment,
allowing for a seamless integration into existing production lines.
Overall, the Semiconductor Cleaning Machine is an essential piece
of equipment for semiconductor manufacturers. Its adjustable
cleaning pressure and wash liquid spray pressure make it a
versatile machine for a variety of cleaning needs, while its high
cleaning capacity and seamless integration into existing production
lines make it a valuable addition to any manufacturing facility.
Features:
- Product Name: Semiconductor Cleaning Machine
- Type: Automatic
- Conveyor Height Width: 900±50mm
- Conveyor Net Width: 600mm
- Cleaning Pressure: 3~8kg/cm2
- Package Size: L600*W500*T100mm As Max
- For water based flux and other contamination
- Kevlar transport nets
- 304 stainless steel frame structure
- DI water wash+ DI water rinse+ Hot air dry process
Technical Parameters:
| Material | SUS304 Stainless Steel |
| Air Filter | 1umx1pcs; 0.01umx1pcs |
| Conveyor Height Width | 900±50mm |
| Cleaning Capacity | 100 Wafers Per Hour |
| Di Water Supply | ＞17MΩ(Flow Rate＞7RPM)Wash and rinse DI water add/discharge
automatically. |
| Cleaning Method | Ultrasonic |
| Package Size | L600*W500*T100mm As Max |
| Dimensions | 8250*1970*1770(L*W*H) |
| Conveyor Direction | Left To Right Or Right To Left |
| Power Supply | 380V/50Hz |
| Other Features | PLC control system, English interface and friendly operation
system, 304 stainless steel frame structure. |
Applications:
The SME-8200 model is a top-of-the-line semiconductor cleaning
machine that is designed to meet the demands of modern industries.
It has a conveyor height width of 900±50mm, making it suitable for
a variety of applications. This automatic cleaning machine is made
of SUS304 stainless steel, ensuring durability and longevity.
One of the key features of this cleaning machine is that it washes
and rinses DI water automatically. This ensures that the cleaning
process is efficient and consistent, producing high-quality results
every time. Additionally, the wash liquid spray pressure can be
adjusted for different chips, making this cleaning machine
versatile and adaptable to different scenarios.
The SME Electromechanical PLC Drive Cleaning Machine Purification
System 8200 is perfect for businesses that require a high-quality
cleaning solution for their semiconductor products. It is suitable
for a variety of applications, including the cleaning of
microchips, optical devices, and electronic components. With a
minimum order quantity of 1, this product is accessible to
businesses of all sizes.
To ensure the safe delivery of the cleaning machine, it is packaged
in a wooden case. The delivery time for this product is 45 days,
and payment terms require 100%TT. The supply ability of this
product is 10, ensuring that there is always stock available for
businesses that require it.
Customization:
- Brand Name: Sme Electromechanical PLC Drive Cleaning Machine
Purification System 8200 Specifications Sufficient Supply Delivery
- Model Number: SME-8200
- Place of Origin: china
- Certification: ISO9001
- Minimum Order Quantity: 1
- Price: 3999999
- Packaging Details: wooden case
- Delivery Time: 45 days
- Payment Terms: 100%TT
- Supply Ability: 10
- Material: SUS304 Stainless Steel
- DI Water Supply: ＞17MΩ (Flow Rate＞7RPM)
- Type: Automatic
- Conveyor Net Width: 600mm
- Cleaning Pressure: 3~8kg/cm2
Our Semiconductor Cleaning Machine customization services also
include:
- SMEMA lines to connect up and down stream equipment.
- DI water wash+ DI water rinse+ Hot air dry process.
- FCBGA/FCCSP Semi chips in line clean in packaging process.
Support and Services:
The Semiconductor Cleaning Machine product is equipped with
advanced technical support and services to ensure optimal
performance and customer satisfaction. Our team of experts is
available to provide assistance with installation, operation,
maintenance, and troubleshooting of the machine. We offer regular
training programs to educate customers on the proper usage of the
machine and its components. Our comprehensive warranty program
covers all parts and labor for a specified period of time.
Additionally, we provide customized service contracts to meet
specific customer needs. Our goal is to deliver reliable and
efficient solutions to our customers.
Packing and Shipping:
Product Packaging:
- 1 Semiconductor Cleaning Machine
- 1 Power Cord
- 1 User Manual
- 1 Warranty Card
Shipping:
- Ships within 45 days of order confirmation
- Free shipping within China
- International shipping available for an additional fee
- Shipped in a sturdy cardboard box with protective foam inserts
