    Printer Long Squeegee Automatic Batch Cleaning Machine For Screen Printing Process

    Ask Lasest Price
    Brand Name : SHENHUA
    Model Number : SME-280
    Certification : CE,UL
    Price : negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 200 sets per year
    Delivery Time : 30~40 days
    • Product Details
    • Company Profile

    Printer Long Squeegee Automatic Batch Cleaning Machine For Screen Printing Process

    High efficient 900mm length ink screen printing squeegee batch cleaning machine is a new type oil squeegees auto cleaning machine. Screen printing machine squeegees are very hard to clean beause the corners at the 2 end of them; cracks of squeegees and fixing plates are also hard to be cleared.


    SME-280 is an off-line, compact, energy-saving , batch cleaning screen printing squeegee cleaning machine. SME-280 can automatically complete the cleaning, rinsing, drying process in one chamber by just push" start" key.


    Machine Features:
    1. Special designed to clean printing oil, silver paste and other organic and inorganic contaminations on Squeegees .
    2. Ultrasonic and spray clean at the same time to clean all the oil off from the squeegees.
    3. Clean,rinse,dry process, thoroughly clean, standby and ready to use at any time.
    4. 6 squeegee racks : can clean 6pcs 900mm squeegees in one time.
    5. State of the process is visible through a large observation window.
    6. Clean detergent heat system heat cleaning detergent to a certain temp, raise cleaning efficiency and reduce clean time.
    7. Easy operation interface, quick setting clean parameters. Different passwords can be set.
    8. Inner filter makes detergent used repeated. .
    9. Totally SUS304 structure, very firm and attractive.

    Machine Spec:
    ItemSME-280 Spec
    Squeegee numbers4pcs of 900mm squeegees one time, 8 pcs of 400mm one time
    clean lqiuid tank capacity120L
    rinse water tank capacity120L
    Clean time5~10min
    Rinse time1~2min
    Dry time10~30min
    cleaning liquid heat tempRoom temp~60ºC
    Dry tempRoom temp~99ºC
    water tempRoom temo~60ºC
    Cleaning liquid filter1um
    Rinse water filter1um
    clean/ rinse pump1.1KW
    ultrasonic power1.2KW
    Power/air supplyAC380V/50A/50HZ,30KW;0.5Mpa
    Machine sizeL1600 x W1600 x H1400(mm)
    Machine weight600KG


    Comparison pictures before and after cleaning:
